Renewable Design for Bonded Bar Tendons - ASTM A722 Post-Tensioning Bars 40mm,50mm – Cathay

Renewable Design for Bonded Bar Tendons - ASTM A722 Post-Tensioning Bars 40mm,50mm – Cathay Featured Image
  • Renewable Design for Bonded Bar Tendons - ASTM A722 Post-Tensioning Bars 40mm,50mm – Cathay

Short Description:


Download as PDF

Product Detail

Parameter

Mechanical Properties

Product Tags

Related Video

Feedback (2)

Dedicated to strict high-quality management and considerate purchaser support, our experienced employees members are usually available to discuss your specifications and be certain full shopper satisfaction for Bar Post Tension Tendon, Steel Bar For Prestressed Concrete, Thread Steel Bars For The Prestressing, We have been normally seeking forward to forming profitable company relationships with new clientele around the environment.
Renewable Design for Bonded Bar Tendons - ASTM A722 Post-Tensioning Bars 40mm,50mm – Cathay Detail:

System Description:

The screw thread steel bars for the prestressing of concrete manufactured by our company is a high tensile alloy steel bar which features a coarse right-hand thread over its full length and available in two standard lengths, namely 9m and 12m,yet,special length is negotiable based on user’s demand subject to the maximum length of 18m.

The screw thread steel bars:

Fully Threaded Bar - can be cut and coupled at any point.

Low Relaxation Steel - minimum relaxation during service life.

Prestressing Grade Steel - high strength offers weight savings and reduced working diameters.

Grade PSB500，PSB830，PSB930，PSB1080
Diameter 15mm,0mm,25mm,32mm,36mm,40mm,50mm

Applications:

Our thread bar systems are used for connections, formwork and anchorages and have been installed in large-scale construction projects worldwide. Whether for building, underground, bridge or road construction, tunnelling or mining.



Stock with fastest dlievery

IMG_0574

Product detail pictures:

Renewable Design for Bonded Bar Tendons - ASTM A722 Post-Tensioning Bars 40mm,50mm – Cathay detail pictures

Related Product Guide:
We always do the job to be a tangible group making sure that we can provide you with the top top quality as well as ideal value for Renewable Design for Bonded Bar Tendons - ASTM A722 Post-Tensioning Bars 40mm,50mm – Cathay, The product will supply to all over the world, such as: Philippines, Egypt, Turin, When It produced, it making use of the world's major method for reliable operation, a low failure price, it appropriate for Jeddah shoppers choice. Our enterprise. s situated inside the national civilized cities, the website traffic is very hassle-free, unique geographical and financial circumstances. We pursue a "people-oriented, meticulous manufacturing, brainstorm, make brilliant" company philosophy. Strict good quality management, fantastic service, affordable cost in Jeddah is our stand around the premise of competitors. If needed, welcome to make contact with us by our web page or phone consultation, we will be delighted to serve you.

continuous threaded bar

Nominal Diameter Diameter H B L Nominal Section Nominal Weight
Dv Dh
mm mm mm mm mm mm mm2 kg/m
15 15 15 1.0 4.5 10 176 1.47
18 18 18 1.0 4.0 10 254.5 2.11
20 20 20 1.3 4.8 10 314 2.47
25 25 25 1.6 6.0 12 490.9 4.10
32 32 32 2.0 7.0 16 804.2 6.65
36 36 36 2.5 8.0 18 1018 8.41
40 40 40 3.0 8.0 20 1256.6 10.34
50 50 50 3.0 9.0 24 1963.5 16.28
60 60 60 3.0 10.0 22 2827 23.26
63.5 63 63.5 3.0 12.0 22 3167 26.20
65 65 65 3.0 12.0 22 3318 27.470
70 70 70 3.0 12.0 22 3848 31.8
75 75 75 3.0 12.0 22 4418 36.9
Grade500/630 NominalDia. CrossSection YieldStrength TensileStrength YieldLoad UltimateLoad Elongation NominalWeight
mm mm2 >=Mpa >=Mpa KN KN A/% KG/m
20 314 500 630 157 198 10 2.47
25 491 500 630 246 309 10 4.1
28 615 500 630 308 387 10 4.83
